Description

Specification

Unit

Rated operating load

5000

kg

Bucket capacity

2.5~4.5

m³

Machine weight

17500±300

kg

Dump clearance at maximum lift

3100~3780

mm

Reach at maximum lift

1100~1220

mm

Wheel base

3300

mm

Tread

2250

mm

Max. breakout force

175±5

kN

Max. horse power

160±5

kN

Hydraulic cycle time - raise

≤6

s

Total hydraulic cycle time

≤10.5

s

Min. turning radius over tyres

5925±50

mm

Articulation angle

38

°

Gradeability

30

°

Tyre size

23.5-25-16PR

-

Overall machine dimension L×W×H

8225×3016×3515

mm

Engine Model

WD10G220E21

-

Rated Power

162

kW

Travel speed - I-gear (F/R)

13/17

km/h

Travel speed - II-gear (F)

41

km/h
