ENGINE

Unit

Value

Model

-

BF6M2012-17T2

Type

-

Four-stroke, twincharged, inter-cooled

Rated power

kW@rpm

127

Max. torque

Nm@rpm

700@1500

Displacement

ml

6060

No. of cylinders

-

6

Cylinder bore x stroke

Φ×mm

101×126

Emission

-

GB 20891-2007(China phase II)

HYDRAULIC SYSTEM

Hydraulic system type

-

Double pump constant power positive flow control

Main pump

-

-

Max flow rate

L/min

2×230+18

Relief valve setting

-

-

Implement circuit

bar

34/35.5

Travel circuit

bar

363

Swing circuit

bar

279

Pilot circuit

bar

390

ELECTRICAL SYSTEM

System voltage

V

28

Battery voltage

V

24

Battery capacity

Ah

140

Alternator voltage

V

28

Starter voltage

V

24

DRIVE AND BRAKES

Drive motor

-

-

Max drawbar pull

kN

203

Max travel speed (low/high)

km/h

3.5/5.7

Service/parking brakes

-

Wet and disc type

Gradeability

°

35

SWING SYSTEM

Swing motor

-

-

Swing brake

-

Wet and disc type

Swing speed

r/min

12.1

UNDER CARRIAGE

No. of track shoes

-

49×2

No. of top rollers

-

2×2

No. of bottom rollers

-

2×8

No. of track guards

-

2×2

SERVICE REFILL CAPACITY

Fuel tank

L

390

Engine coolant

L

23.3

Engine oil

L

19

Swing drive

L

2×2

Travel drive

L

5×2

Hydraulic tank

L

110

Hydraulic system

L

220
