Parameter

Value

Operating Weight (kg)

34800 kg

Bucket capacity (m³)

1.9 m³

Bucket capacity range

1.6~2.0

Average ground pressure

63.8 mm

Slewing speed

10.7 r/min

Traveling speed (low/high)

3.0/5.0 km/h

Maximum digging force

222.6 kN

Altitude

2000 m

Wading depth

815 mm

Engine model/Drive Motor Model

BFM8-29T2

Engine power

215 kW

Maximum flow rate

2×290+25.5 L/min

English Parameter

Value

Fuel specifications and filling amount

590L

Overall length

11000mm

Overall width

3190mm

Overall height

3450mm

Boom length

6200mm

Wheel track

2590mm

Arm length

3200mm

Wheelbase

4130mm

Crawler wheelbase/Wheelbase

4130mm

Maximum digging radius

10860mm

Maximum digging depth

7220mm

Maximum discharge height

7090mm

Overall length during transfer

11000mm

Shovel width (with band edge)

1670mm

Maximum digging depth under length of bottom surface of 2.5m

7025mm

Maximum digging height

10045mm

Contour dimension of complete machine (transfer position)

11000×3190×3450mm

Overall width of upper assembly

2950mm

Overall width of chassis

3190mm

Overall height to cab top

3150mm

Rear slewing radius

3530mm

Overall height to hood top

2885mm

Ground clearance of upper assembly

1215mm

Overall length of crawler

5070mm

Wheel track of crawler/Wheel track

2590mm

Track shoe width

600mm

Minimum ground clearance

520mm

Overall height of working mechanism during transfer

3450mm

Maximum digging radius of reference ground

10650mm

Maximum vertical digging depth

5420mm

Minimum front turning radius

4180mm
