Operating Weight (kg)

15950kg

Bucket capacity (m³)

0.6m³

Slewing speed

12.2r/min

Traveling speed (low/high)

3.6/37.5km/h

Maximum digging force

75.7kN

Altitude

1700m

Wading depth

380mm

Engine model/Drive Motor Model

BF4M1013-16T2

Engine power

116KW

Maximum flow rate

2X150+20L/min

Fuel specifications and filling amount

290L

Overall length

7770mm

Overall width

2520mm

Overall height

3190mm

Boom length

4600mm

Wheel track

1944

Arm length

2100mm

wheelbase

2600mm

Crawler wheelbase/Wheelbase

2600mm

Maximum digging radius

8210mm

Maximum digging depth

4995mm

Maximum discharge height

5870mm

Overall length during transfer

7770mm

Shovel width (with band edge)

1153mm

Maximum digging depth under length of bottom surface of 2.5m

4775mm

Maximum digging height

8840mm

Contour dimension of complete machine (transfer position)

7770*2520*3190mm

Overall width of upper assembly

2490

Overall width of chassis

2520mm

Overall height to cab top

3190mm

Rear slewing radius

2230mm

Overall height to hood top

2760mm

Ground clearance of upper assembly

1200mm

Wheel track of crawler/Wheel track

1944mm

Minimum ground clearance

350mm

Overall height of working mechanism during transfer

3060mm

Maximum digging radius of reference ground

7985mm

Maximum vertical digging depth

4190mm

Minimum front turning radius

2595mm
