Overall Dimension

Transmission System

L×W×H

7320×2520×3170 mm

Torque converter

Single-stage four-element double-turbine hydraulic torque converter

Wheel base

2850 mm

Transmission type

Planetary power shift

Min. ground clearance

370 mm

Gears

Forward 2 / Reverse 1

Max. dumping height

2930 mm

Speed at forward gear I

0~13 km/h

Lifting height

3790 mm

Speed at forward gear II

0~38 km/h

Dumping distance

1140 mm

Speed at reverse gear I

0~17 km/h

Dumping angle

-45°

Hydraulic System (Working Device)

Bucket rollback at ground level

44°

Type

Hydraulic pilot control

Steering angle

37°

Total time

≤ 9.2 s

Horizontal crossing radius

6065 mm

Brake System

Min. turning radius

5250 mm

Service brake type

Air over oil caliper disc brake

Overall Parameters

Parking brake type

Manual control internal expanding shoe brake

Bucket capacity

2.1 m³

Steering System

Rated load

3500 kg

Type

Load sensing full hydraulic articulated steering

Operating weight

11230 kg

Max. tractive force

100 kN

System pressure

12 MPa

Max. breakout force

≥96 kN

Fill Capacity

Tipping load

≥70 kN

Fuel

200 L

Engine

Hydraulic oil

128 L

Model

WP6G125E22

Engine oil

18 L

Type

Inline, water-cooled, four-stroke, direct injection

Transmission oil

44 L

Rated power

105 kW

Drive axle oil

28 + 28 L

Rated speed

2200 r/min

Engine displacement

6750 ml

Braking system fluid

-

Cylinder bore/stroke

105/130 mm

Max. torque / speed

560 N·m / 1400~1600 r/min

Emission standard

GB 20891-2007

Min. fuel-consume ratio

215 g/kW·h
