Description

Specification

Unit

Rated operating load

3000

kg

Bucket capacity

1.5~2.5

m³

Machine weight

10900±200

kg

Dump clearance at maximum lift

2770~3260

mm

Reach at maximum lift

1010~1210

mm

Wheel base

2900

mm

Tread

1850

mm

Height of hinge at maximum lift height

3830

mm

Working height (fully lifted)

4870

mm

Max. breakout force

130

kN

Max. horse power

95

kN

Hydraulic cycle time - raise

5.4

s

Total hydraulic cycle time

9.3

s

Min. turning radius over tyres

5170

mm

Articulation angle

38±1

°

Gradeability

28

°

Tyre size

17.5-25-12PR

-

Overall machine dimension L×W×H

7245×2482×3320

mm

Engine Model

WP6G125E201

-

Emission standards

Emission 2

-

Rated Power/Speed

92/2000

kW/rpm

Fuel Tank

170

L

Hydraulic Tank

175

L

Travel speed - I-gear(F/R)

46372

km/h

Travel speed - II-gear(F/R)

38/-

km/h
